Kitronik Dice Project Kit

The LED torch uses a white 5000mCd ultra bright LED. Power is supplied by an N size 12 volt battery, which is included in the kit. The torch comes complete with a slide on off switch.

Contents:

1 x N Size Holder.

1 x N Size 12V Battery.

1 x White 5mm Water Clear LED – 15deg – 5000mCd.

1 x 680R Resistor.

1 x PCB Mount Slide Switch.

1 x White LED Torch Project Kit PCB

Build and play with your own electronic games using the Kitronik Game Project Kit. This engaging electronics kit combines learning and fun by allowing users to assemble a fully working game console featuring two classic games: a Memory Game and a Reaction Game.

Powered by a pre-programmed PIC microcontroller, the kit introduces learners to soldering, electronics assembly and circuit design while providing an enjoyable gaming experience once completed. The compact PCB design includes four LEDs and four push buttons, with an integrated battery holder and power switch mounted directly onto the board for a self-contained project.

The finished kit can be used as built or incorporated into a custom enclosure designed by the user, making it an excellent project for STEM learning, electronics clubs and budding engineers.

Games Included

Memory Game: This is our take on the classic ‘Simon Says’ game. You have to match the pattern shown by the 4 LEDs in the order shown by the kit before the timer runs out!

Reaction Game: This game tests how fast your reactions are! The kit lights up an LED where you have to press the corresponding button on the same corner as the LED. The game times out if you press the wrong corresponding button or don’t press the button in time.

Kit Contents:

1 x Electronic Game Kit PCB

1 x Pre-programmed PIC IC.

1 x 2 x AA PCB-mounted battery holder

1 x 8-pin IC socket

1 x PCB-mounted slide switch.

4 x PCB-mounted tactile switches.

1 x Red, 1 x Green, 1 x Yellow, 1 x Orange 5mm diffused LED.

6 x 680Ω resistors.

1 x 47Ω resistor

1 x M3 machine screw

1 x M3 hex nut

This light-activated kit is also available as a temperature-activated project kit. The output of this board can be used to control other electronic circuits, turning them on automatically when it goes light or dark.

The board has space for an LED with a current limit resistor (both available separately) which will light when the output turns on.

The Darlington pair transistor configuration allows an output current of up to half an amp to be controlled. Operating voltage 3V to 12V (lower voltages allow for better adjustment of the switching point).

Note: This kit requires soldering.

Features:

This Light Switch Kit detects the brightness of its surroundings using a Phototransistor.

The kit acts as an automated on/off switch (light dependable) for many devices.

Contents:

1 x 1MΩ Potentiometer.

2 x BC337 NPN Transistors.

1 x Phototransistor.

1 x 220Ω Resistor.

1 x Light Activated Switch PCB

Possible applications include:

Garden light that switches on automatically at night.

Drawer alarm, which sounds when a dark drawer is opened.

Line following robot (using 2 light-activated boards).

This learn to solder pack is the ideal low cost solution for teaching soldering in the classroom/after school club. The pack provides all of the parts and PCB's required for a class size of 25 and also includes a 9V battery for testing purposes. Each pack comprises; 25 x PCBs, 100 x 100 ohm resistors, 25 x LED's, and a 9V PP3 battery.

There is also a step by step guide to soldering, which covers; equipment, solder, tinning & cleaning, soldering in 8 steps, de-soldering in five steps, wire preparation, examples of good and bad solder joints, basic PCB repair, resistor information, LED information, full step by step build information for the kit, and how the learn to solder kit works. This guide covers everything that you might need to discuss with students and can form the basis of your lesson plan.

Using the kits and the step by step guide, each student will solder four resistors and one LED to their PCB before pressing it to the terminals of the 9V battery to check that their board works. Using the guides they will be able to examine their own work and troubleshoot problems. The battery pads on the PCBs have been shaped inline with the battery terminals on a PP3 battery making it straightforward to see which way around it should be placed on the battery.

Features:

Purpose built PCBs that can be tested, once built, with the supplied 9V PP3 battery.

Low cost classroom pack for 25 students.

Easy build kit.

Full teaching resources and step by step guides available for this kit below.

Contents:

100 x 100 ohm Resistors.

25 x Red 5mm Diffused LED - 275mCd.

25 x Learn To Solder PCBs.

1 x 9V Zinc Chloride PP3 Battery.

Dimensions:

Built Height: 11mm.

PCB Length: 31mm.

PCB Width: 21mm.

PCB Height: 1.5mm.

Requires:

Soldering Iron.

Solder.

Wire Cutters.

The Kitronik 5V LED Desk Lamp Kit provides a bright and efficient lighting solution in a compact, easy-to-mount design. Equipped with nine white super flux LEDs, it delivers a total output of approximately 16,000 mCd. Built-in current limit resistors ensure safe operation from a 5V power supply or 3 x AA batteries, offering up to 5 hours of illumination with fresh batteries.

2 x AA Battery Cage with leads, with 150mm colour coded flying leads. This battery cage houses two AA batteries and is barely bigger than the batteries it is designed to hold. This makes it a suitable choice for the smaller projects when a discrete and easy to hide battery cage is what is called for.

It also features colour coded 150mm flying leads, making for easy integration into your projects.The battery cage can easily be soldered directly to a board or connected to your project via terminal blocks.

Features:

Small discreet size.

150mm colour coded flying leads.

The leads are suitable for soldered connections.

The leads are suitable for terminal block connections.

Contains:

1 x 2 AA Battery Cage with 150mm colour coded flying leads.

Dimensions:

Leads: 150mm
