Kitronik Jumper Wires 20cm Male to Male 40 Pack

This 30cm servo extension cable has three 22-AWG wires joining a male Futaba J connector and a female JR connector. Since a female JR connector can be plugged into a male Futaba J connector, each end of the cable is compatible with both Futaba and JR-style connections; this cable will work as an extension cable in either system or as an adapter between systems, and it is compatible with almost all of the servos in the Kitronik range

The connectors have contacts on a 0.1" spacing, and each wire is comprised of 60 strands, making this cable more flexible than standard servo cables.

Features:

Compatible with all standard servo types including a Mini 180 degree servo.

Also compatible with a Mini 360 degree continous rotation servo.

Servo cable colour convention:

Brown or black = ground (GND, battery negative terminal).

Red = servo power (Vservo, battery positive terminal).

Orange, yellow, white, or blue = servo control signal line

This is a 4 pack of wires that are pre-terminated with an alligator (crocodile) clip on one end and a hookup pigtail (male jumper connector) on the other. Alligator clips are a staple part for any workbench and with these cables you will be able to easily incorporate those clips into a breadboard, development platform, or anything else that you would normally be able to attach a male jumper connector to.

Each Alligator Clip with Pigtail cable has a wire length of 30cm (that’s a little less than 1ft) and a male pin that easily inserts into a standard 0.1" connector. Each pack consists of two red cables and two black cables.

These connector wires can also be used to connect a BBC microbit to a prototyping board as an alternative to an edge connector.

Features:

Wires with a croc clip on one end and a male jumper cable connector (pigtail) on the other.

Enables you to connect a BBC microbit to a prototyping board as an alternative to using an edge connector.

Contents:

2 x Red alligator to male jumper connector leads.

2 x Black alligator to male jumper connector leads.

Dimensions:

Length: 30cm.

Official micro:bit branded USB cables that allow you to power and transfer data to your micro:bit.

Alligator clips (or Crocodile clips, if you prefer) are likely to be the most useful thing on your workbench besides the workbench itself. Whether you're just trying to make a few quick connections to test your circuit or having trouble making your multimeter leads stay where you need them, these spring-loaded clips are a workshop must-have.

Each lead in this pack of 3 is 35cm long with a rubber shrouded alligator clip in 45mm length and 8.3mm opening on each end. There are three different colours, you get each of: red, black and yellow.

This 1M White Anti-Tangle USB Type-A to Micro-B USB Noodle cable is a flat type USB cable. The new flat design means that the cable resists tangling, ensuring that when it is taken out of where it is stored it's tangle free and ready to go.

This USB cable is compatible with the BBC micro:bit and can be used with the newer LilyPad boards.

Features:

1m length cable.

Anti tangle design.

Micro-B USB 5-pin port.

USB 2.0 Type A port.

Can be used with the BBC micro:bit.

Can be used with the newer LilyPad boards.

Contents: 1 x 1M White Anti-Tangle USB Type-A to Micro-B USB Cable.

Dimensions:

Cable Length: 1m.

USB Type A Head Length: 28mm.

USB Type A Head Width: 15mm.

USB Micro-B Head Length: 23mm.

USB Micro-B Head Width: 11mm.

Compatible with:

Raspberry Pi Pico

Micro:Bit

This is the perfect cable choice for those that want to output music or general sound for the BBC micro:bit, to either headphones or speakers.

At one end of the cable are the black and red crocodile clips, which connect to the microbits GND and Pin 0 respectively. At the other end of the cable is a 3.5mm TRS (tip, ring sleeve) stereo jack.

The 3.5mm TRS stereo jack means you can either connect your headphones directly to your BBC micro:bit or if you would rather use a speaker, you can use one of our MP3 mono amplifier kits to drive the speaker.

Note:Although the BBC micro:bit can supply enough current to drive a pair of headphones, you will need an amplifier if you wish to drive an audio speaker. A MP3 mono amplifier kit is an ideal choice as it offers both the amplifier and speaker. Please be aware however this lead does not work with true Mono leads and is designed to work with Stereo Leads.

Features:

Plug headphones directly onto the 3.5mm TRS stereo jack.

Crocodile clips for direct connection to the BBC micro:bit.

Contents:

1 x BBC micro:bit Audio Cable.

Dimensions:

Length: 400mm.

Clips: 28mm.

These 4 pin dual female connectors are compatible with the Grove range of products. The plug into both the grove modules and grove compatible interfaces such as the Grove micro:bit interface.

It is supplied as a pack of 5 and each of the connector wires are 300mm in length.

Plug one end into a Grove module and the other into a Grove, or grove compatible, interface and you are ready to go, plug and play!

Note: The colours may vary from those displayed in the product images.

Features:

Compatible with all Grove products.

Supplied as a pack of 5.

Each is 300mm in length.

Contents:

1 x 5 Pack of 4 Pin Dual Female connectors.

Dimensions:

Length: 300mm.

These are 20cm long jumpers with female connectors on both ends. Use these to jumper from any male header on any board to any other female header. Multiple jumpers can be installed next to one another on a 0.1" (2.54mm) header.

Features:

Female to Female connectors.

20cm Long.

For use with breakout boards with a standard 0.1" (2.54mm) pin spacing.

1 x 40 pack F/F Jumpers (four of each colour).
