KKSB Case for Raspberry Pi 5 and M.2 NVMe HAT+

Protect and showcase your Raspberry Pi 5 with the Pimoroni NVMe Base Case — a stylish and practical enclosure designed to house both your Pi 5 and an NVMe Base or NVMe Base Duo for high-speed SSD storage.

The Pimoroni NVMe Base Case offers a neat, professional housing solution for your Raspberry Pi 5 and an NVMe Base or NVMe Base Duo. Crafted with precision and ventilation in mind, this case keeps your system cool and organised while showing off your hardware setup.

It’s perfect for anyone building a compact file server, home media hub, or workstation using NVMe storage. The case provides easy access to all ports and indicators, and comes with spacers, fixings, and a cooling fan mount for reliable performance.

The Raspberry Pi M.2 HAT+ enables you to connect M.2 peripherals such as NVMe drives and AI accelerators to Raspberry Pi 5’s PCIe 2.0 interface, supporting fast (up to 500 MB/s) data transfer to and from NVMe drives and other PCIe accessories.

Raspberry Pi 5’s single-lane PCI Express 2.0 interface is exposed on a 16-pin, 0.5mm- pitch FPC connector; the M.2 HAT+ M Key is a mechanical adapter board that converts between this connector and a subset of the M.2 standard. It supports devices that have the M.2 M key edge connector, in the 2230 and 2242 form factors. It is capable of supplying up to 3A to connected M.2 devices.

The Raspberry Pi M.2 HAT+ conforms to the Raspberry Pi HAT+ specification and is autodetected by the latest Raspberry Pi software/firmware. It is supplied with a 16mm stacking header and threaded spacers, so it can be fitted to a Raspberry Pi 5 with the Raspberry Pi Active Cooler in place.

The Raspberry Pi Active Cooler provides an alternative cooling solution for users who wish to use their Raspberry Pi 5 under sustained heavy load without a case.

The Active Cooler combines a large metal heatsink with a high-quality variable-speed blower fan, powered and controlled via the fan connector on the Raspberry Pi 5, attached to the board via sprung pins into the dedicated pair of mounting holes.

As the heat from the Pi 5 CPU spreads across the heatsink body and fins, the blower fan pushes cool air over them to keep your Raspberry Pi 5 running at optimal thermal levels. The cooler uses thermal pads to create a solid thermal connection with the Raspberry Pi 5.

The fan is software-controlled, allowing it to remain off (and therefore silent) until temperatures reach the specified threshold.

Features

Compatible with Raspberry Pi 5

Large metal 'finned' heatsink combined with a high-quality blower fan

Fan fitting compatible with the Raspberry Pi 5 fan connector

Variable speed fan (software/temperature controlled)

Uses the Raspberry Pi 5 heatsink mount holes

Thermal pads included (pre-fitted)

Raspberry Pi not included

Compatible with:

Raspberry Pi 5

The new High Quality 16mm 10MP Telephoto Camera Lens from Raspberry Pi is compatible with C or CS-mount lenses.

Please note: Raspberry Pi High Quality Camera not included - available separately here.

The 16mm 10MP Telephoto lens offers a high level of zoom, for targeting your camera on specific subjects. The lenses screw directly onto the Raspberry Pi High Quality Camera and feature multiple adjustment options (via thumbscrews) for greater flexibility and image refinement. Covers for the front and rear of the lenses are included and come pre-fitted.

Features

Compatible with the Raspberry Pi High Quality Camera

Thumbscrew adjustment

Covers on front and back

Compatible with:

Raspberry Pi 4

Raspberry Pi 5

Raspberry Pi Zero
