MonkMakes CO2 Sensor for micro:bit

The Octopus CO2 Gas Sensor, part of the OCTOPUS series, features a consistent design with the same outlook, PCB fixing holes, and connections as its counterparts. As CO2 concentration increases, the output voltage decreases, allowing users to easily obtain CO2 readings through our brochures and coding samples.

The CO2 probe is crafted from industrial-grade materials, rendering it highly responsive to CO2 while resisting interference from alcohol and CO. It excels in performance with rapid response times, even in varying temperature and humidity conditions. Additionally, the onboard heating circuit efficiently converts 5V to a stable 6V voltage, enhancing the adaptability of the CO2 Gas Sensor.

Please note that this sensor requires a breakout board for operation, and it is typically paired with the Elecfreaks IOT:BIT board by the manufacturer.

Add line following functionality to the Kitronik MOVE mini MK2 for the BBC micro:bit with this easy to assemble add-on kit. This version of the line following add on has been designed to fit both the new :MOVE mini MK2 and the original version. The assembly instructions for both can be found in the Resources section below.

This add-on comes with all the parts required to add line following functionality to the :MOVE mini and does not require any soldering. Once built, the sensitivity of the left and right sensors can be individually tweaked to ensure smooth operation.

See the resource section below to download the line following code example we created. By default the code will cause the buggy to follow a dark line on a light background but the code can be altered to do the opposite.

There is no soldering required but the kit does require some mechanically assembly.

Features:

Add line following functionality to the :MOVE mini for the BBC micro:bit.

Can either follow a dark line on a light back ground or a light line on a dark background.

The line following sensitivity can be adjusted with a screwdriver.

No Soldering required.

Example line following code is provided.

This product is backwards compatible with the first version of :MOVE mini. There are two sets of assembly instructions in the resources section below.

Contents:

1 x :MOVE Sensor Interface for the BBC micro:bit.

1 x :MOVE Line Following board for the BBC micro:bit.

1 x Connector Cable.

2 x CS M3 8mm Screws.

2 x M3 Hex Full Width Nut.

5 x CS M3 12mm Screws.

2 x 6mm Spacers.

2 x 12mm CS Screws.

The Mini Prong soil sensor is a short version of the original Prong sensor that has been specially adapted for use with the Kitronik Greenhouse Kit for BBC micro:bit. The Mini Prong soil moisture sensor for BBC microbit is a sensor board that can be connected to a BBC micro:bit with crocodile clips to monitor the moisture present in the soil. The two conductive tines are placed into the soil. Any water or moisture in the soil will conduct to give an analogue voltage that can be read by the BBC micro:bit.

Mini Prong is powered from the 3V supply of the BBC micro:bit. Use either the USB or JST connector on the BBC micro:bit to power the circuit. The board has been designed to work with croc-clips, to connect between the Mini Prong and the BBC micro:bit. When fitted to the Mini Prong moisture sensor, the micro:bit can be coded via any of the micro:bit editors, such as the Microsoft MakeCode editor. The Datasheet at the foot of this page includes technical information and a MakeCode blocks coding example.

Note: To ensure that the mini Prong moisture sensor has a long and fulfilling life, it is better to write your code to perform a moisture check every so often rather than continuously. When the check is performed continuously it promotes rapid erosion of the electrodes.

Features:

Measure soil moisture levels.

Attach to the micro:bit with crocodile clips.

Compatible with both BBC micro:bit V1 and BBC micro:bit V2.

Write code for it with any micro:bit coding editor.

Dimensions:

Length: 33mm.

Height: 43mm.

PCB Thickness: 1.6mm.

Expand the scope of your :MOVE mini Robotics projects to include sensory input via our :MOVE Sensor Interface Board for the BBC microbit. The board acts as a breakout board for the microbit while it is attached to a Servo:Lite board and allows you to add things such as line following boards, ultrasonic sensors, and much more.

Sensory input can allow for your projects to become more autonomous as they react to their surroundings and perform actions based on this. There is no soldering required, the board is screwed directly to the BBC microbit and Servo:Lite assembly with the five screws that are supplied with the board.

Features:

Add external sensor input to the BBC microbit.

Expand the scope and function of your :MOVE mini Robots.

Adding sensors to :MOVE mini allows it to react to its environment.

Contents:

1 x :MOVE Sensor Interface for the BBC micro:bit.

5 x CS M3 12mm Screws.

2 x 5 PCB pin headers.

1 x small Kitronik keyring.

Dimensions:

Max Height: 48mm.

Max Width: 52mm.

PCB Thickness: 1.5mm.

The Prong soil moisture sensor for BBC microbit is a sensor board that can be directly mounted to a BBC micro:bit to monitor the moisture present in the soil. The two conductive tines are placed into the soil. Any water or moisture in the soil will conduct to give an analogue voltage that can be read by the BBC micro:bit.

Prong is powered from the 3V supply of the BBC micro:bit. Use either the USB or JST connector on the BBC micro:bit to power the circuit. Prong and the BBC micro:bit can also be powered from the Mi:Power board to create a compact stand-alone unit.

The board has been designed so that the BBC micro:bit can be bolted on using 3 x M3 nuts and 3 x M3 screws. Place the screws through the P1, 3V and GND holes of the PCB and BBC micro:bit, then use the M3 nuts to fasten together on the back of BBC micro:bit. Alternatively, croc-clips can be used to connect between the Prong and the BBC micro:bit.

If using the Mi:Power board then additionally connecting P0 means the BBC micro:bit can sound an alarm if the soil becomes too dry. When fitted to the Prong moisture sensor, the micro:bit can be coded via any of the micro:bit editors, such as the Microsoft MakeCode editor.

Note: To ensure that the Prong moisture sensor has a long and fulfilling life, it is better to write your code to perform a moisture check every so often rather than continuously. When the check is performed continuously it promotes rapid erosion of the electrodes.

Features:

Measure soil moisture levels.

Attaches directly to the microbit.

Use in conjunction with the Mi:Power board to provide power and an audible alarm.

Code with any microbit coding editor.

Contents:

1 x Prong Soil Moisture Sensor for microbit.

3 x M3 Hex Nuts.

3 x M3 Countersunk Screws.

Dimensions:

Length: 68mm.

Height: 53mm.

PCB Thickness: 1.6mm.

Add obstacle detection to your robotics, electronics, or Arduino project. This module has been specially selected to work on the voltage range typically found with the Arduino range of products. This economical sensor provides 2cm to 400cm of non-contact measurement functionality with a ranging accuracy that can reach up to 3mm. Each HC-SR04 module includes an ultrasonic transmitter, a receiver and a control circuit.

There are only four pins that you need to worry about on the HC-SR04: VCC, Trig, Echo and GND. VCC and GND are for power and Trig, Echo and GND are for your signal. GND is in with the signal set since it's needed for a baseline. You can easily add this to your project and even use with the microbit if you use a separate 5V power supply.

Features:

Add obstacle detection to your robotics, electronics, or Arduino project.

It can also be added to micro:bit projects provided a separate power supply is used.

It provides 2cm to 400cm of non-contact measurement functionality

It has ranging accuracy that can reach 3mm.

Each HC-SR04 module includes an ultrasonic transmitter, a receiver and a control circuit.

The pins are; VCC, Trig, Echo and GND

Dimensions:

Length: 45mm.

Width: 20mm.

Max height: 15mm.

Pin Pitch: 2.54mm

The MonkMakes CO₂ Mini Kit for BBC micro:bit allows students to measure and explore carbon dioxide (CO₂) levels in indoor environments using real sensor data. Designed for education, this compact kit is ideal for projects linked to air quality, climate science, and environmental monitoring.

The kit connects easily to the BBC micro:bit and uses a reliable CO₂ sensor to provide accurate readings, making it suitable for classroom investigations, STEM clubs, and project work. Students can log data, set alerts, and visualise changes in CO₂ levels over time using MakeCode or Python, helping to build skills in data handling, coding, and scientific enquiry.

This kit is particularly useful for lessons around ventilation, indoor air quality, sustainability, and climate awareness, making abstract environmental concepts tangible and measurable.

Key features:

CO₂ sensing kit designed for BBC micro:bit

Measures indoor carbon dioxide levels for air quality studies

Ideal for STEM, science, geography, and environmental projects

Supports MakeCode and Python

Compact format, suitable for classroom and student use

The MonkMakes Sensor Board allows you to detect sound levels, temperature and light levels. It features ring pad connectors for use with crocodile clips make it easy to connect to the board to a microbit.

Sound Level: It senses sound level with a MEMs, which is a microphone on a chip that also features a pre-amplifier circuit. You can then use the plot bar graph block in the Microsoft MakeCode editor to display the result on the microbits LED matrix.

Temperature Level: The temperature output from the board is a voltage that indicates the temperature. This is then measured using an analog input on the micro:bit. If you want your temperatures in Fahrenheit, then multiply the temperature in degrees C by 9, divide the result by 5 and then add 32.

Light Level: The light sensor uses a photo-transistor to measure the light level and produces an output voltage that increases as the light level increases.

Features:

3V and GND connections can be made from either side and allow you to power a second board such as the MonkMakes Relay Board or MonkMakes Speaker.

LED ‘power on’ indicator.

Reverse polarity protection.

All three sensors are analog and can be connected to pins P0, P1 and P2 using alligator clips.

Detects sound level with a MEMs (microphone on a chip) and a pre-amplifier.

Uses a thermistor to measure temperature.

Light level detection with a photo-transistor (0 to 1023).

All three sensors are analog and can be connected to pins P0, P1 and P2 using alligator clips.

Dimensions:

Length: 63.2mm.

Width: 55.7mm.

Thickness: 1.6mm.
