From the same category
40-pin GPIO Booster Header for Raspberry Pi
PIM COM0003
These headers will give your HAT or pHAT a real lift! We all love playing with the latest Pi accessories, but sometimes we've found that these wonderful add-on boards could do with just a little more clearance from the top of the Raspberry Pi.
That's where these little headers come in! They're standard 2x20 GPIO headers so are suitable for all 40-pin versions of the Raspberry Pi, but they have 5mm pins to make sure they mate securely with the female headers on your add-on board.
Datasheet
Compatible with:Raspberry Pi 5 Raspberry Pi 4
That's where these little headers come in! They're standard 2x20 GPIO headers so are suitable for all 40-pin versions of the Raspberry Pi, but they have 5mm pins to make sure they mate securely with the female headers on your add-on board.
Datasheet
Compatible with:
€2.95
Kitronik Autonomous Robotics Buggy for Raspberry Pi Pico
KI 5335
The Kitronik Autonomous Robotics Platform Pico, a fun and hands-on introduction to Robotics with the Raspberry Pi Pico. The Kitronik Autonomous Robotics Platform for Raspberry Pi Pico is a fun and hands-on introduction to buggy robotics. The easy to follow booklet provided with the kit guides you through all of the steps required for you to take control of your robot. The Robotics Platform has been designed to grow with you and provided additional servo and ultrasonic sensor connectors for more advanced projects. This buggy requires a Raspberry Pi Pico with pin headers attached.
The kit is supplied with the autonomous robotics platform chassis, 2 wheels and tyres, a Kitronik line-following sensor board, and an ultrasonic sensor. The kit requires no soldering and only minimal mechanical assembly. Fit the tyres to the wheels, push the wheels onto the pre-mounted motors and both the line following sensor and ultrasonic distance sensor plug straight into the board. Once put together, push the Raspberry Pi Pico into the onboard connector, add 4 x Alkaline AA batteries to the battery holders underneath and you are done. Your robot buggy is ready for instruction.
The included booklet guides you through every step of getting to know your robot. It contains a detailed assembly guide, info on preparing the Raspberry Pi Pico, instructions for installing an editor (Thonny), and instructions on how to write code for every feature of the Robotics Platform. No corner of the board is left unexplained. As well as the easy-to-follow getting started guide, Kitronik have also produced online tutorials which go into more detail on coding the key features of the board. The links to the tutorials can be found in the resources section at the foot of this page.
For those that like to modify their robot buggies, the buggy has 4 x threaded mounting points added to the chassis, 3 x M3 & 1 x M4. These mechanical fixing locations enable the addition of user-designed features, such as cosmetic chassis parts and/or additional robotic features, such as appendages. Kitronik have produced a dxf file showing the location and thread size of each of these mechanical fixing locations, it can be downloaded in the resources section below. The zip file also contains a jpg for those that don't have access to CAD or viewing software.
To help make programming the robot as simple as possible, Kitronik has developed a set of Micropython modules, which can be found here. More information on this can be found in the booklet supplied with the kit. If you aren't familiar with GIT, we've created an online beginners' guide to help you get up to speed. You can find the guide here (https://kitronik.co.uk/GitGuide).
Features:A fun and hands-on introduction to buggy robotics. The Robotics Platform has been designed to grow with you, start small then add complexity later. The kit ships with a detailed guide booklet backed up with freely available online tutorials. The autonomous robotics platform introduces the user to light, movement, and sensing so the robot can be as hands-on or hands-off as want it to be. Program your buggy to react to the world around it. Learn to code with MicroPython, using our simple-to-follow guides and the beginner-friendly Thonny editor. Just add the Raspberry Pi Pico, some alkaline batteries, and some code and watch your buggy come to life! This buggy is not supplied with a Pico, you can obtain a Raspberry Pi Pico here. It also features 4 x threaded mounting points added to the chassis, 3 x M3 & 1 x M4.
Contents:1 x Autonomous robotics buggy chassis PCB. 2 x Kitronik 5 spoke wheels and tyres. 1 x Kitronik line following sensor board. 1 x Ultrasonic Sensor.
Dimensions:PCB Length: 126mm. PCB Width: 80mm. Wheel Diameter (with tire): 67.5mm.
Compatible with:Raspberry Pi Pico
The kit is supplied with the autonomous robotics platform chassis, 2 wheels and tyres, a Kitronik line-following sensor board, and an ultrasonic sensor. The kit requires no soldering and only minimal mechanical assembly. Fit the tyres to the wheels, push the wheels onto the pre-mounted motors and both the line following sensor and ultrasonic distance sensor plug straight into the board. Once put together, push the Raspberry Pi Pico into the onboard connector, add 4 x Alkaline AA batteries to the battery holders underneath and you are done. Your robot buggy is ready for instruction.
The included booklet guides you through every step of getting to know your robot. It contains a detailed assembly guide, info on preparing the Raspberry Pi Pico, instructions for installing an editor (Thonny), and instructions on how to write code for every feature of the Robotics Platform. No corner of the board is left unexplained. As well as the easy-to-follow getting started guide, Kitronik have also produced online tutorials which go into more detail on coding the key features of the board. The links to the tutorials can be found in the resources section at the foot of this page.
For those that like to modify their robot buggies, the buggy has 4 x threaded mounting points added to the chassis, 3 x M3 & 1 x M4. These mechanical fixing locations enable the addition of user-designed features, such as cosmetic chassis parts and/or additional robotic features, such as appendages. Kitronik have produced a dxf file showing the location and thread size of each of these mechanical fixing locations, it can be downloaded in the resources section below. The zip file also contains a jpg for those that don't have access to CAD or viewing software.
To help make programming the robot as simple as possible, Kitronik has developed a set of Micropython modules, which can be found here. More information on this can be found in the booklet supplied with the kit. If you aren't familiar with GIT, we've created an online beginners' guide to help you get up to speed. You can find the guide here (https://kitronik.co.uk/GitGuide).
Features:
Contents:
Dimensions:
Compatible with:
€54.95
Kitronik Motor Driver Board for Raspberry Pi Pico
KI 5331
Make the Raspberry Pi Pico the core of your new buggy project with the Kitronik Compact Motor Driver Board for Raspberry Pi Pico.
This board allows the Raspberry Pi Pico (connected via pin header) to drive two motors simultaneously with full forward, reverse & stop control, making it ideal for Pico-controlled buggy projects. Alternatively, the board can be used to power a stepper motor. The board features the DRV8833 motor driver IC, which has built-in short circuit, over current and thermal protection. Please note, when used with a stepper motor, half-stepping is supported - but not micro-stepping.
The board has 4 external connections to GPIO pins and a 3V and GND supply from the Pico. This allows for additional IO options for your buggy builds that can be read or controlled by the Pico. In addition, there is an on/off switch and power status LED, allowing you to see at a glance if the board is powered up and save your batteries when your project is not in use.
To use the motor driver board, the Pico should have a soldered pin header and be inserted firmly into the connector. The board produces a regulated supply that is fed into the 40-way connector to power the Pico, removing the need to power the Pico directly. The motor driver board is powered via either screw terminals or a servo-style connector.
Note Due to the additional current draw of a Pico W's wireless features it is not recommended to use the wireless functionality with this board. The Pico's W standard functionality will work as normal only the wireless functions are affected.
Features:A compact yet feature-packed board designed to sit at the heart of your Raspberry Pi Pico robot buggy projects. The board can drive 2 motors simultaneously with full forward, reverse, and stop control. It features the DRV8833 motor driver IC, which has built-in short circuit, over current and thermal protection. Additionally, the board features an on/off switch and power status LED. Power the board via a terminal block-style connector. The 3V and GND pins are also broken out, allowing external devices to be powered. Code it with MicroPython via an editor such as the Thonny editor. When used with a stepper motor, half-stepping is supported - but not micro-stepping.
Dimensions:Length: 63mm. Width: 35mm. Height: 11.6mm. PCB Thickness: 1.6mm Mounting Holes (Diameter): 3mm.
Compatible with:Raspberry Pi Pico
This board allows the Raspberry Pi Pico (connected via pin header) to drive two motors simultaneously with full forward, reverse & stop control, making it ideal for Pico-controlled buggy projects. Alternatively, the board can be used to power a stepper motor. The board features the DRV8833 motor driver IC, which has built-in short circuit, over current and thermal protection. Please note, when used with a stepper motor, half-stepping is supported - but not micro-stepping.
The board has 4 external connections to GPIO pins and a 3V and GND supply from the Pico. This allows for additional IO options for your buggy builds that can be read or controlled by the Pico. In addition, there is an on/off switch and power status LED, allowing you to see at a glance if the board is powered up and save your batteries when your project is not in use.
To use the motor driver board, the Pico should have a soldered pin header and be inserted firmly into the connector. The board produces a regulated supply that is fed into the 40-way connector to power the Pico, removing the need to power the Pico directly. The motor driver board is powered via either screw terminals or a servo-style connector.
Note Due to the additional current draw of a Pico W's wireless features it is not recommended to use the wireless functionality with this board. The Pico's W standard functionality will work as normal only the wireless functions are affected.
Features:
Dimensions:
Compatible with:
€14.95
Kitronik Pin Breakout for the Raspberry Pi Pico
KI 5341
The Kitronik Pin Breakout for the Raspberry Pi Pico has been designed to offer an easy way of connecting additional circuitry and devices to the Pico. It also allows for moving the Pico between projects without the need to remove all of the jumper cables.
The Pico plugs into the two inner rows of sockets. The remaining two outer rows can then be used for connecting to external devices/circuits. The board has clear markings for each pin and the correct orientation for inserting the Pico is also clearly marked.
In order to use this board, the Pico should have soldered pin headers, it can then be firmly inserted into the board. Additionally, the board features 4 x M3 mounting holes to allow for fixing the board to projects/prototyping setups. Care was taken when designing the Pico Pin Breakout to maintain as small a footprint as possible.
Features:It offers a convenient interface for controlling additional circuitry with the Raspberry Pi Pico. The board features 2 x rows of sockets that a Pico with soldered pin headers can slot straight into. The outer rows of sockets can be used to connect any of the Pico i/o pins to a project/prototype. Use jumper wires, soldering is not required. Raspberry Pi Pico prototyping made easy.
Dimensions:Length: 65mm. Width: 37mm. Height: 11.2mm.
Compatible with:Raspberry Pi Pico
The Pico plugs into the two inner rows of sockets. The remaining two outer rows can then be used for connecting to external devices/circuits. The board has clear markings for each pin and the correct orientation for inserting the Pico is also clearly marked.
In order to use this board, the Pico should have soldered pin headers, it can then be firmly inserted into the board. Additionally, the board features 4 x M3 mounting holes to allow for fixing the board to projects/prototyping setups. Care was taken when designing the Pico Pin Breakout to maintain as small a footprint as possible.
Features:
Dimensions:
Compatible with:
€5.25
Kitronik Robotics Board for Raspberry Pi Pico
KI 5329
Make the Raspberry Pi Pico the core of your new robotics project with the Kitronik Compact Robotics Board for Raspberry Pi Pico.
This Compact Robotics Board enables the Raspberry Pi Pico (connected via pin header) to drive 4 motors (or 2 stepper motors) and 8 servos. It also features 27 other I/O expansion points and Power and Ground connections. Please note, when used with a stepper motor, half-stepping is supported - but not micro-stepping.
The Robotics Board features 2 Dual H Bridge Motor Driver ICs. These are capable of driving 2 standard motors or 1 stepper motor each, with full forward, reverse, and stop control. There are also 8 servo outputs, capable of driving standard and continuous rotation servos. They can all be controlled by the Pico using the I2C protocol, via a 16-channel driver IC. The IO break-out provides connections to all the unused pins on the Pico. The 27 available I/O pins allow other devices, such as sensors or ZIP LEDs, to be added to the board.
Power is provided via either a terminal block or servo-style connector. The supply is then controlled by an on/off power switch to the board and there is also a green LED to indicate when the board has power. The board then produces a regulated 3.3V supply which is fed into the 3V and GND connections to power the connected Pico. This removes the need to power the Pico separately. The 3V and GND pins are also broken out on the header, which means external devices can also be powered.
To use the robotics board, the Pico should be firmly inserted into the dual row pin socket on the board. Ensure the Pico is inserted with the USB connector at the same end as the power connectors on the robotics board. This will allow access to all of the board functions and each pin broken out.
Note Due to the additional current draw of a Pico W's wireless features it is not recommended to use the wireless functionality with this board. The Pico's W standard functionality will work as normal only the wireless functions are affected.
Features:A compact yet feature-packed board designed to sit at the heart of your Raspberry Pi Pico robotics projects. The board can drive 4 motors (or 2 stepper motors), with full forward, reverse, and stop control, and 8 servos. It also features 27 other I/O expansion points and Power and Ground connections. The I2C communication lines are also broken out allowing other I2C compatible devices to be controlled. Additionally, the board features an on/off switch and power status LED. Power the board via either a terminal block or servo style connector. The 3V and GND pins are broken out to solder pads, allowing external devices to be powered. Code it with MicroPython via an editor such as the Thonny editor. When used with a stepper motor, half-stepping is supported - but not micro-stepping.
Compatible with:Raspberry Pi Pico
This Compact Robotics Board enables the Raspberry Pi Pico (connected via pin header) to drive 4 motors (or 2 stepper motors) and 8 servos. It also features 27 other I/O expansion points and Power and Ground connections. Please note, when used with a stepper motor, half-stepping is supported - but not micro-stepping.
The Robotics Board features 2 Dual H Bridge Motor Driver ICs. These are capable of driving 2 standard motors or 1 stepper motor each, with full forward, reverse, and stop control. There are also 8 servo outputs, capable of driving standard and continuous rotation servos. They can all be controlled by the Pico using the I2C protocol, via a 16-channel driver IC. The IO break-out provides connections to all the unused pins on the Pico. The 27 available I/O pins allow other devices, such as sensors or ZIP LEDs, to be added to the board.
Power is provided via either a terminal block or servo-style connector. The supply is then controlled by an on/off power switch to the board and there is also a green LED to indicate when the board has power. The board then produces a regulated 3.3V supply which is fed into the 3V and GND connections to power the connected Pico. This removes the need to power the Pico separately. The 3V and GND pins are also broken out on the header, which means external devices can also be powered.
To use the robotics board, the Pico should be firmly inserted into the dual row pin socket on the board. Ensure the Pico is inserted with the USB connector at the same end as the power connectors on the robotics board. This will allow access to all of the board functions and each pin broken out.
Note Due to the additional current draw of a Pico W's wireless features it is not recommended to use the wireless functionality with this board. The Pico's W standard functionality will work as normal only the wireless functions are affected.
Features:
Compatible with:
€24.95
Kitronik Simply Robotics Motor Driver Board for Raspberry Pi Pico
KI 5348
Make the RiPi Pico the hub of your next robot/buggy project with The Kitronik Simply Robotics Board for Raspberry Pi Pico.
The Kitronik Simply Robotics Board for Raspberry Pi Pico features 2 Dual H-Bridge Motor Driver ICs (capable of driving 2 brushed motors or 1 stepper motor) and 8 servo outputs (capable of driving standard and continuous rotation servos), all controlled from a Raspberry Pi Pico. The Raspberry Pi Pico is not included.
The Motor Driver ICs are capable of up to 1A per channel and can drive a variety of small motors, such as hobby motors and more. They feature built-in protection for overcurrent, which can be reset by power cycling the board. The board features standard 3-pin servo connectors which allow for servos to be plugged straight in without the need for additional adaptors or soldering.
The IO breakout provides connections to 5 GPIO pins, including the Analogue inputs on the Pico. These IO points allow input devices, for example, sensors, or output devices, such as ZIP LEDs, to be added to the board. The board also features 3 x holes for mounting the board to a surface or custom enclosure, the mounting holes are 3.3mm in diameter (M3 clearance).
Power is provided via a terminal block. The supply is controlled by an on/off power switch to the board. There is a green LED to indicate when the board is turned on. The board then produces a regulated supply which is fed into the connected Pico, removing the need to power the Pico separately. There are 3V and GND pins broken out on the additional header, which means external devices can also be powered.
Note:This board is capable of continuous use at high currents. During such use, it may become hot.
Features:Control up 8 servos and two motors (or a stepper motor) simultaneously with the Raspberry Pi Pico. The board requires a Pico with headers attached Ample IO for advanced robotics projects. The onboard servo connectors are standard 3-pin servo connectors. The board also features 5 GPIO pins, including the Analogue inputs on the Pico. These IO points allow input devices, for example, sensors, or output devices, such as ZIP LEDs. Power is provided via a terminal block power input connector, with an on/off switch and power status LED. The Simply Robotics board will power all of the attached servos and provide the attached Pico with a regulated 3V supply. Additionally, there is built-in reverse polarity protection.
Dimensions:Length: 63mm. Width: 42mm. Max Height: 10mm. Mounting Holes Diameter: 3.3mm (M3)
Compatible with:Raspberry Pi Pico
The Kitronik Simply Robotics Board for Raspberry Pi Pico features 2 Dual H-Bridge Motor Driver ICs (capable of driving 2 brushed motors or 1 stepper motor) and 8 servo outputs (capable of driving standard and continuous rotation servos), all controlled from a Raspberry Pi Pico. The Raspberry Pi Pico is not included.
The Motor Driver ICs are capable of up to 1A per channel and can drive a variety of small motors, such as hobby motors and more. They feature built-in protection for overcurrent, which can be reset by power cycling the board. The board features standard 3-pin servo connectors which allow for servos to be plugged straight in without the need for additional adaptors or soldering.
The IO breakout provides connections to 5 GPIO pins, including the Analogue inputs on the Pico. These IO points allow input devices, for example, sensors, or output devices, such as ZIP LEDs, to be added to the board. The board also features 3 x holes for mounting the board to a surface or custom enclosure, the mounting holes are 3.3mm in diameter (M3 clearance).
Power is provided via a terminal block. The supply is controlled by an on/off power switch to the board. There is a green LED to indicate when the board is turned on. The board then produces a regulated supply which is fed into the connected Pico, removing the need to power the Pico separately. There are 3V and GND pins broken out on the additional header, which means external devices can also be powered.
Note:This board is capable of continuous use at high currents. During such use, it may become hot.
Features:
Dimensions:
Compatible with:
€17.00
Kitronik Simply Servos Board for Raspberry Pi Pico
KI 5339
Make the RiPi Pico the brains of your next robotics project with the Kitronik Simply Servos for Raspberry Pi Pico.
The compact Simply Servo board for Raspberry Pi Pico allows for up to 8 servos to be controlled simultaneously, making it ideal for advanced robotics projects with the RiPi Pico. The board should be used with a Pico that has soldered pin headers, the Pico can then slot straight into the board. A Pico with pin headers already attached can be obtained separately here. The board features standard 3-pin servo connectors which allow for servos to be plugged straight in without the need for adaptors or soldering.
As well as supporting 8 servos, the board also features 5 external connections to GPIO pins and a 3V and GND supply from the Pico. This IO breakout the 3 ADC pins and GP0 and GP1. This allows additional IO to be connected to the board and the state of these can then be read or controlled by the Pico.
Power is provided via a terminal block connector, the supply is then controlled by an on/off power switch to the board. There is a green power LED to indicate when the board is turned on. The board produces a regulated 3V supply that is fed into the 40-way connector to power the Pico, removing the need to power the Pico directly. The board's power connections are reverse polarity protected.
Note: This board is capable of continuous use at high currents. During such use, it may become hot. Also due to the additional current draw of a Pico W's wireless features it is not recommended to use the wireless functionality with this board. The Pico's W standard functionality will work as normal only the wireless functions are affected.
Features:Control up 8 servos simultaneously with the Raspberry Pi Pico. Ample IO for advanced robotics projects. The board features standard 3 pin servo connectors. The board also features 5 external connections to GPIO pins and a 3V and GND supply from the Pico. These IO breakout the 3 ADC pins and GP0 and GP1. The board features a terminal block power input connector, with on/off switch and power status LED. The board will power all of the attached servos and provide the attached Pico with a regulated 3V supply. Additionally, there is built-in reverse polarity protection. Kitronik has developed a MicroPython module & sample code.
Compatible with:Raspberry Pi Pico
The compact Simply Servo board for Raspberry Pi Pico allows for up to 8 servos to be controlled simultaneously, making it ideal for advanced robotics projects with the RiPi Pico. The board should be used with a Pico that has soldered pin headers, the Pico can then slot straight into the board. A Pico with pin headers already attached can be obtained separately here. The board features standard 3-pin servo connectors which allow for servos to be plugged straight in without the need for adaptors or soldering.
As well as supporting 8 servos, the board also features 5 external connections to GPIO pins and a 3V and GND supply from the Pico. This IO breakout the 3 ADC pins and GP0 and GP1. This allows additional IO to be connected to the board and the state of these can then be read or controlled by the Pico.
Power is provided via a terminal block connector, the supply is then controlled by an on/off power switch to the board. There is a green power LED to indicate when the board is turned on. The board produces a regulated 3V supply that is fed into the 40-way connector to power the Pico, removing the need to power the Pico directly. The board's power connections are reverse polarity protected.
Note: This board is capable of continuous use at high currents. During such use, it may become hot. Also due to the additional current draw of a Pico W's wireless features it is not recommended to use the wireless functionality with this board. The Pico's W standard functionality will work as normal only the wireless functions are affected.
Features:
Compatible with:
€9.95
Kitronik ZIP96 Retro Gamer for Raspberry Pi Pico
KI 5347
Develop your coding skills with the Kitronik ZIP96 Retro Gamer for Pico, 'the' all-in-one handheld solution for Pico gaming!
The Kitronik ZIP96 is a fully programmable feature-packed retro-styled handheld gaming solution for the Raspberry Pi Pico. It's fully loaded with awesome features, including a 96 LED display, that can be fully controlled with code for a complete gaming experience. Kitronik has developed a set of lesson plans for this product, that enables successful Computing lessons at KS3/4 (US equivalent - Grades 6-8/9-10). Though developed for use in the classroom, the ZIP96 Retro Gamer is ideal for anyone who already has a Pico or sees a Pico in their immediate future.
The ZIP96 features 96 colour fully addressable LEDs arranged in a 12 x 8 display, a buzzer for audio feedback, a vibration motor for haptic feedback, and 6 input buttons (typical use; 4 x directional buttons and 2 x action buttons). It also breaks out GP1, GP11, ADC1 and ADC2, along with a set of 3.3V and GND for each, to standard 0.1” footprints. GP18 to 21 are also broken out on a 0.1” footprint underneath the Pico. The Pico is connected via low-profile 20-way pin sockets.
To use the ZIP96 Gamer the Pico should have a soldered pin header and be inserted firmly into the connector. The ZIP96 does not ship with a Pico. Power is provided via the built-in 3 individual AA battery holders which have been ergonomically placed on the underside of the board to act as hand grips, which makes the ZIP96 comfortable to hold and play.
Features:A feature-packed all-in-one retro-styled handheld gaming solution for the Raspberry Pi Pico. Packed with awesome features that can be controlled with code for the ultimate handheld pico gaming experience. The ZIP96 features 96 colour fully addressable LEDs arranged in a 12 x 8 display. The board features a built-in buzzer for audio feedback and a vibration motor for haptic feedback. There are 6 input buttons (typical use; 4 x directional buttons and 2 x fire buttons). It also breaks out GP1, GP11, ADC1 and ADC2, along with a set of 3.3V and GND for each, to standard 0.1” footprints. GP18 to 21 are also broken out on a 0.1” footprint underneath the Pico. The Pico is connected via pre-fitted low-profile 20-way pin sockets. Ergonomically placed AA battery holders that power the board AND function as comfortable handgrips. Kitronik has a Github repo containing MicroPython module and sample code to support using the ZIP96 Gamer with the Raspberry Pi Pico. Kitronik has produced a set of lesson plans to enable successful Computing lessons at KS3/4 (US equivalent - Grades 6-8/9-10). The Datasheet provides additional usage information, electrical specifications, and dimensions.
Compatible with:Raspberry Pi Pico
The Kitronik ZIP96 is a fully programmable feature-packed retro-styled handheld gaming solution for the Raspberry Pi Pico. It's fully loaded with awesome features, including a 96 LED display, that can be fully controlled with code for a complete gaming experience. Kitronik has developed a set of lesson plans for this product, that enables successful Computing lessons at KS3/4 (US equivalent - Grades 6-8/9-10). Though developed for use in the classroom, the ZIP96 Retro Gamer is ideal for anyone who already has a Pico or sees a Pico in their immediate future.
The ZIP96 features 96 colour fully addressable LEDs arranged in a 12 x 8 display, a buzzer for audio feedback, a vibration motor for haptic feedback, and 6 input buttons (typical use; 4 x directional buttons and 2 x action buttons). It also breaks out GP1, GP11, ADC1 and ADC2, along with a set of 3.3V and GND for each, to standard 0.1” footprints. GP18 to 21 are also broken out on a 0.1” footprint underneath the Pico. The Pico is connected via low-profile 20-way pin sockets.
To use the ZIP96 Gamer the Pico should have a soldered pin header and be inserted firmly into the connector. The ZIP96 does not ship with a Pico. Power is provided via the built-in 3 individual AA battery holders which have been ergonomically placed on the underside of the board to act as hand grips, which makes the ZIP96 comfortable to hold and play.
Features:
Compatible with:
€48.95 €35.95
MonkMakes Illuminata LED Bulb for Pi Pico
MONK 098
This board is designed to make it easy to attach a high-brightness bulb to a Raspberry Pi, Pico, Arduino, ESP32 or other microcontrollers.
Most microcontrollers and single board computers (SBCs) like the Raspberry Pi have digital outputs that can only supply a current of a few milliamps. This means that you can only use them with low-power LEDs, but if you want to control a high-power LED light bulb then you need to use the microcontroller or SBC's output pin to switch the LED light bulb on and off (using a transistor).
The illuminata includes a transistor to switch its three high-brightness LEDs on and off. This is why the Illuminata has three pins. Two are for power and the third is the control pin that switches the lamp on and off.
Features3V to 6V operation. Built-in MOSFET for PWM and on/off control Pre-soldered pin headers (GND, Control and +V) Breadboard friendly Laser-cut diffuser (superglue required) Cool Aluminum PCB M2.5 mounting holes
Compatible with:Raspberry Pi Pico
Most microcontrollers and single board computers (SBCs) like the Raspberry Pi have digital outputs that can only supply a current of a few milliamps. This means that you can only use them with low-power LEDs, but if you want to control a high-power LED light bulb then you need to use the microcontroller or SBC's output pin to switch the LED light bulb on and off (using a transistor).
The illuminata includes a transistor to switch its three high-brightness LEDs on and off. This is why the Illuminata has three pins. Two are for power and the third is the control pin that switches the lamp on and off.
Features
Compatible with:
€5.95
Pimoroni Display HAT Mini for Raspberry Pi
PIM 589
A generous 2.0" (320 x 240) IPS LCD display for Raspberry Pi with lots of tasty baked in functionality.
Display HAT Mini features a bright 18-bit capable 320x240 pixel display with vibrant colours and formidable IPS viewing angles, connected via SPI. It's got four tactile buttons for interacting with your Pi with your digits and a RGB LED for notifications. Pimoroni have also squeezed in a QwST connector (Qwiic / STEMMA QT) and a Breakout Garden header so it's a doddle to connect up different kinds of breakouts.
It will work with any model of Pi with a 40 pin header, it goes with the Raspberry Pi Zero particularly well - Pimoroni have included a pair of standoffs so you can use to bolt HAT and Pi together to make a sturdy little unit. To accommodate the screen Display HAT Mini is a bit bigger than a standard mini HAT or pHAT - it's around 5mm taller than a Pi Zero (so a Mini HAT XL or a Mini HAT Pro, if you will).
Display HAT Mini lets you turn a Raspberry Pi into a convenient IoT control panel, a tiny photo frame, digital art display or gif-box, or a desktop display for news headlines, tweets, or other info from online APIs. This screen is a handy 3:2 ratio, useful for retro gaming purposes!
Features:2.0” 320x240 pixel IPS LCD screen, connected via SPI (~220 PPI, 65K colours) 4 x tactile buttons RGB LED Qw/ST (Qwiic/STEMMA QT) connector Breakout Garden / I2C header Pre-soldered socket header for attaching to Raspberry Pi Compatible with all models of Raspberry Pi with a 40 pin header. Fully assembled No soldering required (as long as your Pi has header pins attached). Dimensions: approx 65.5mm x 35mm x 9mm (W x H x D, includes header and display). With a Pi Zero attached with standoffs, the total depth is 17mm. Screen usable area: 40.8mm x 30.6mm (L x W) Pinout Schematic Dimensional drawing Display HAT Mini Python library ST7789 Python library
IncludesDisplay HAT Mini 2 x 10mm standoffs
Compatible with:Raspberry Pi 5 Raspberry Pi 4 Raspberry Pi Zero(but needs Male 40-pin 2x20 HAT Header for Pi Zero)
Display HAT Mini features a bright 18-bit capable 320x240 pixel display with vibrant colours and formidable IPS viewing angles, connected via SPI. It's got four tactile buttons for interacting with your Pi with your digits and a RGB LED for notifications. Pimoroni have also squeezed in a QwST connector (Qwiic / STEMMA QT) and a Breakout Garden header so it's a doddle to connect up different kinds of breakouts.
It will work with any model of Pi with a 40 pin header, it goes with the Raspberry Pi Zero particularly well - Pimoroni have included a pair of standoffs so you can use to bolt HAT and Pi together to make a sturdy little unit. To accommodate the screen Display HAT Mini is a bit bigger than a standard mini HAT or pHAT - it's around 5mm taller than a Pi Zero (so a Mini HAT XL or a Mini HAT Pro, if you will).
Display HAT Mini lets you turn a Raspberry Pi into a convenient IoT control panel, a tiny photo frame, digital art display or gif-box, or a desktop display for news headlines, tweets, or other info from online APIs. This screen is a handy 3:2 ratio, useful for retro gaming purposes!
Features:
Includes
Compatible with:
€26.95
