Raspberry Pie Pimoroni Explorers Hat Pro for 40 Pin

The Raspberry Pi 400 kit is a complete personal computer built into a compact keyboard, with everything you need in the box (minus a monitor or TV)! It’s ideal for learning to code using the Raspberry Pi OS desktop environment and can also be used for a wide range of other activities such as surfing the web, creating and editing documents, watching videos and more!

The Pi400 shares the same great performance as the Raspberry Pi 4 but with the 64-bit CPU clocked to a whopping 1.8GHz thanks to the large internal heatsink. This sits alongside 4GB RAM, dual-band wireless networking, dual-display output and 4K video playback.

The familiar 40-pin GPIO pins are located at the rear of the keyboard for wiring up electronics projects, alongside two USB 3.0 ports and a USB 2.0 port. There's even an on/off power option via the F10 key (for full power disconnection, grab a USB-C on/off switch cable).

The Raspberry Pi 400 kit which includes everything you need to get started in the box (minus a monitor).

The Raspberry Pi 400 keyboard

An Official Raspberry Pi USB-C power supply

An Official Raspberry Pi USB mouse

A 16GB microSD card pre-programmed with Raspberry Pi OS

An Official 1m micro-HDMI cable

Official Beginners Guide

Compatible with:

Raspberry Pi 4

The Raspberry Pi 4 Model B is the best performing single-board computer to date from the Raspberry Pi Foundation that has undergone a huge upgrade in comparison to all previous models. For the first time, the Pi 4 B is available in different memory versions, this model has 4GB with true Gigabit Ethernet, USB-C power, USB 3.0, dual 4k display output and a quad-core CPU to rival the performance of an entry-level desktop PC. It’s a truly powerful and capable computer in a small, affordable package.

The Raspberry Pi 4 has received a performance boost to 1.5GHz with an upgraded quad-core processor.

The fanless, energy-efficient Raspberry Pi runs silently and uses far less power than other computers.

Memory size of 4GB to enable more complicated processes to run efficiently.

Dual micro-HDMI ports enables a dual screen set-up.

Up to 4K resolution video decoding.

Raspberry Pi 4 has upgraded USB capacity: along with two USB 2 ports you'll find two USB 3 ports, which can transfer data up to ten times faster.

Bluetooth 5.0 and WiFi - an improvement on the previous Bluetooth 4.2 on the Pi 3 B+

Raspberry Pi 4 comes with Gigabit Ethernet, along with onboard wireless networking and Bluetooth.

Power is supplied via USB-C – Raspberry Pi 3 was powered via micro-USB at 5.1v

The Raspberry Pi Camera Module 3 is the latest entry in the Official Raspberry Pi range of camera modules, offering a new 12 Megapixel Sony IMX708 image sensor, powered autofocus, improved low-light sensitivity and HDR (High Dynamic Range) support for your Raspberry Pi projects!

The module is capable of 4608x2592 pixel images and 4608x2592 @14 FPS/2304x1296 @56 FPS/1536x864 @120FPS video. When HDR is enabled, the resolution is limited to 2304x1296 @ 30 FPS.

Accessories

The Camera Module 3 is mechanically identical to the previous Camera Module V2 apart from the front sensor section. The new sensor is larger and may not fit all previous camera accessories. We have updated all of our camera accessories with compatibility information in the descriptions.

Software

The Camera Module 3 can only be used with libcamera - the previous raspistill/raspivid libraries will not work

You will need to update Raspberry Pi OS as the Camera Module 3 requires a new driver and a specific version of libcamera

Boards

The Camera Module 3 is compatible with all Raspberry Pi boards with a full-size camera connector (CSI connector)

-- To use this camera with a Raspberry Pi 5 (which has a smaller CSI connector), you will need to use a Raspberry Pi 5 camera adapter cable
-- To use this camera with a Raspberry Pi Zero (which has a smaller CSI connector), you will need to use an adapter cable

Features

Back-illuminated and stacked CMOS 12-megapixel image sensor (Sony IMX708)

High signal-to-noise ratio (SNR)

Built-in 2D Dynamic Defect Pixel Correction (DPC)

Phase Detection Autofocus (PDAF) for rapid autofocus

QBC Re-mosaic function

HDR mode (up to 3-megapixel output)

CSI-2 serial data output

2-wire serial communication (supports I2C fast mode and fast-mode plus)

2-wire serial control of focus mechanism

Compatible with:

Raspberry Pi 4

Raspberry Pi 5

Raspberry Pi Zero

The Raspberry Pi Sense HAT V2 is the perfect product to learn about programming and how we interact with the world around us. With its full array of sensors, the Sense HAT was originally developed for use on the International Space Station, as part of the educational Astro Pi programme run by the Raspberry Pi Foundation in partnership with the European Space Agency.

It is well suited to many projects that require position, motion, orientation, or environmental sensing. The Sense HAT is powered by the Raspberry Pi computer to which it is connected.

An officially supported Python library provides access to all of the on-board sensors, the LED matrix, and the joystick. The Sense HAT is compatible with any Raspberry Pi computer with a 40-pin GPIO header.

Features
The Raspberry Pi Sense HAT V2 is attached on top of the Raspberry Pi via the 40-pin GPIO pins (which provide the data and power interface) to create an ‘Astro Pi’. The Sense HAT has several integrated circuit based sensors can be used for many different types of experiments, applications, and even games.

The sensors enable you to read:

Gyroscope

Accelerometer

Magnetometer

Temperature

Barometric pressure

Humidity

Colour and brightness

The LED Matrix enables you to display the data from the various sensors, it can show you which way is geomagnetic North by programming a compass using the magnetometer or simply be used to play games like Tetris, Pong and Snake with the joystick. The joystick can also be used to enable a human user to interact with the programs running on the Raspberry Pi Sense HAT.

Compatible with:

Raspberry Pi 4

Raspberry Pi 5

Raspberry Pi Zero

The keyboard has three in-built USB 2.0 type-A ports for powering other peripherals (such as the official Raspberry Pi mouse).

Note: If using with a Pi Zero, you'll need a OTG adapter cable.

Keyboard Specification

79-key keyboard (78-key US keyboard)

3 USB 2.0 type-A ports for powering other peripherals

Automatic keyboard language detection

USB type-A to micro USB type-B cable for connection

Compatible with all Raspberry Pi products (with full-size USB ports)

Ergonomic design for comfortable use

Compatible with:

Raspberry Pi 5

Raspberry Pi 4

The official Raspberry Pi Mouse is a 3-button optical mouse with a scroll wheel, designed for comfortable use with your Raspberry Pi.

Mouse Specification

Three-button optical mouse

Scroll wheel

USB type-A connector

Compatible with all Raspberry Pi products (with full-size USB ports)

Ergonomic design for comfortable use

Compatible with:

Raspberry Pi 5

Raspberry Pi 4

Official Raspberry Pi Micro-HDMI to HDMI cable, fully licensed by Raspberry Pi and manufactured for micro-HDMi Raspberry Pi boards - Raspberry Pi 5 and Raspberry Pi 4 Model B.

Perfect for running a dual-screen setup with the new Raspberry Pi 5 or Raspberry Pi 4. Please note: this HDMI cable is not compatible with the Raspberry Pi 2, 3 or Zero.

Features

Micro-HDMI plug to HDMI plug

Triple-layer shielding for better performance from WiFi and Bluetooth connectivity

Officially licensed by the Raspberry Pi foundation

Moulding style may vary slightly between batches

Length : 1m

Compatible with:

Raspberry Pi 4

Raspberry Pi 5

The Raspberry Pi 27W USB-C Power Supply is a high-quality PD (Power Delivery) power supply for a range of PD-enabled USB-C devices, including (and recommended for) the Raspberry Pi 5 and Pi4B!

This high-efficiency (>91%) 27W power supply offers standard PD modes including 5V/3A, 9V/3A, 12V/2.25A and 15V/1.8A, alongside a custom mode for the Raspberry Pi 5, offering 5V/5A. The range of PD voltage options makes it a great PSU for the home - use it with all of your compatible PD devices including phones, laptops and more! As with all PD devices, your device will communicate with the power supply and select the required voltage.

When used with the Raspberry Pi 5, this power supply will provide 5V/5A and enable you to use the board to its full potential and performance, ensuring a full possible current supply to USB devices. The 27W PSU uses high-quality capacitors to ensure a stable and reliable source of power (Rubycon high-voltage, Panasonic low-voltage).

Features

Official Raspberry Pi 27W USB-C Power Supply

Compatible with the Raspberry Pi 5 & Raspberry Pi 4

Compatible with PD (Power Delivery) devices

-- Standard PD modes: 5V/3A, 9V/3A, 12V/2.25A and 15V/1.8A
-- Custom mode for Raspberry Pi 5: 5V/5A

Compatible with:

Raspberry Pi 4

Raspberry Pi 5

The Raspberry Pi 7" Touchscreen Display adds a truly interactive visual capability to the Raspberry Pi. The potential applications are huge and will lead to the emergence of many new innovative projects including tablets, personalised infotainment systems and home automation projects.

To use this display with a Raspberry Pi 5, you will need to buy this adapter cable!

Features
The 7” Touchscreen Monitor for Raspberry Pi gives users the ability to create all-in-one, integrated projects such as tablets, infotainment systems and embedded projects.

The 800 x 480 display connects via an adapter board which handles power and signal conversion. Only two connections to the Pi are required; power from the Pi’s GPIO port and a ribbon cable that connects to Raspberry Pi boards with a DSI connector (not compatible with the Raspberry Pi Zero) / Raspberry Pi 5 requires a separate cable)

Touchscreen drivers with support for 10-finger touch and an on-screen keyboard are integrated into the Raspberry Pi OS for full functionality without a physical keyboard or mouse.

Turn your Raspberry Pi into a touchscreen tablet, infotainment system, or standalone device

Truly Interactive - supports a virtual ‘on-screen’ keyboard, so there is no need to plug in a keyboard and mouse

Make your own ‘Internet of Things’ (IoT) devices including a visual display. Simply connect your Raspberry Pi, develop a Python script to interact with the display, and you’re ready to create your own home automation devices with touchscreen capability

A range of educational software and programs available on the Raspberry Pi are touch-enabled, making learning and programming easier on the Raspberry Pi

Kit Contents

7” Touchscreen Display

Adapter Board

DSI Ribbon cable (not compatible with Raspberry Pi 5, you'll need a separate adapter cable)

4 x stand-offs and screws (used to mount the adapter board and Raspberry Pi board to the back of the display

4 x jumper wires (used to connect the power from the Adapter Board and the GPIO pins on the Pi so the power is shared across both units)

Please Note - Raspberry Pi and Power Supply are not included in this kit

Compatible with:

Raspberry Pi 4

Raspberry Pi 5

The new official Raspberry Pi High Quality Camera module (HQ Camera) for the Raspberry Pi is here - take your Raspberry Pi camera projects up a gear with the 12-megapixel Sony sensor, integrated aluminium tripod mount and interchangeable lens compatibility!

To use this camera with a Raspberry Pi 5, you will need to buy this adapter cable!
To use this camera with a Raspberry Pi Zero, you will need to buy this adapter cable!

This camera module will not function without a lens (purchased separately, options below).
High Quality 6mm Wide Camera Lens from Raspberry Pi
High Quality 16mm 10MP Telephoto Camera Lens from Raspberry Pi

The incredible new High Quality (HQ) Camera module from Raspberry Pi offers a higher resolution (12 megapixels, compared to 8 megapixels), and sensitivity than the previous Camera Module v2. It features a Sony IMX477 sensor, a 200mm FPC cable for connection to your Raspberry Pi, a milled aluminium lens mount with integrated 1/4” -20 tripod mount and focus adjustment ring, and a C- to CS-mount adapter. A lens cover is also included with the module and comes pre-fitted. There’s even a small screwdriver in the box for making adjustments. It’s designed to work with interchangeable lenses in both C- and CS-mount form factors giving you ultimate flexibility with your Raspberry Pi camera projects. A C-CS mount adapter comes pre-fitted to the module.

Familiar coding
The High Quality (HQ) Camera uses the same commands as the standard Raspberry Pi Camera Module, such as libcamera (or raspistill/raspivid if you're using Buster or an even older OS image). Libcamera and similar commands will query the camera firmware for the resolution of the sensors (as they already do today) and will default to 12 megapixels for the High Quality Camera. The drivers for the High Quality (HQ) Camera are built-in to Raspberry Pi OS too, so upgrading your camera project with the High Quality Camera is a simple task.

Magnificent for Makers
A huge range of popular projects from time-lapse photography to Raspberry Pi CCTV-style systems can be made double-awesome with the new High Quality Camera module. Shoot in greater detail, with improved low-light performance and take advantage of the range of available lenses to get the perfect shot.

Incredible for Industry
The High Quality Camera provides an alternative to the Camera Module v2 for industrial and consumer applications, including security cameras which require the highest levels of visual fidelity and/or integration with specialist optics.

In the box

High Quality (HQ) Camera module with integrated tripod mount (fitted)

Lens cover (fitted)

C-CS lens adaptor (fitted)

200mm ribbon cable (fitted)

Small flat-head screwdriver for adjustments

Compatible with:

Raspberry Pi 4

Raspberry Pi 5

Raspberry Pi Zero
