SG Micro:bit V2 Starter Kit

With the Kitronik Compact Robotics Board, the BBC micro:bit can be used to drive 4 motors (or 2 stepper motors) and 8 servos. Coupled with 17 other I/O expansion points, this means the BBC micro:bit can very easily become the core of a whole variety of robotics projects. The board is small on footprint but big on features and connectivity. Please note, when used with a stepper motor, half-stepping is supported - but not micro-stepping.

The Robotics Board features 2 Dual H Bridge Motor Driver ICs (capable of driving 2 standard motors or 1 stepper motor each) and 8 servo outputs (capable of driving standard and continuous rotation servos), all controlled from the BBC micro:bit using the I2C protocol via a 16 channel driver IC. Kitronik's custom MakeCode blocks make using I2C easy, even for novice users.

The Link header breaks out all the usable pins from the BBC micro:bit, and is designed to allow 2.54mm pitch pin header to be easily soldered into place. The 17 available I/O pins allow other input devices, for example, sensors, or output devices, such as ZIP LEDs, to be added to the board. The I2C communication lines are also broken out (Pins 19 & 20), which means other I2C compatible devices can also be added to the board and controlled by the BBC micro:bit.

Power is provided via either a terminal block or servo style connector. The supply is then controlled by an on/off power switch to the board. There is also a green LED to indicate when the board is turned on. The board then produces a regulated 3.3V supply which is fed into the 3V and GND connections to power the connected BBC micro:bit. This removes the need to power the BBC micro:bit separately. The 3V and GND pins are also broken out on the Link header, which means external devices can also be powered.

To use the compact robotics board, the BBC micro:bit should be inserted firmly into the edge connector, with the LEDs and buttons visible from the front.

Kitronik has produced a set of custom blocks for the MakeCode editor to simplify using the Compact Robotics Board for BBC micro:bit. To add them to the editor, select the cog icon in the top right of the editor. Then, select Extensions from the drop-down menu and in the search bar type and enter Kitronik. Pick the Kitronik robotics Board from the list and the new blocks will be added to the menu in the editor.

Features:

A compact yet feature-packed board designed to sit at the heart of your robotics project.

It can drive 4 motors (or 2 stepper motors) and 8 servos.

The board also has 17 other I/O expansion points.

The link header is designed to allow 2.54mm pitch pin header to be used.

The I2C communication lines are also broken out allowing other I2C compatible devices to be controlled.

This board also features an on/off switch and power status LED.

Power the board via either a terminal block or servo style connector.

The 3V and GND pins are also broken out on the Link header, allowing external devices to be powered.

Code with the Microsoft MakeCode editor with custom blocks by Kitronik or with Python.

When used with a stepper motor, half-stepping is supported - but not micro-stepping.

Contents:

1 x Compact Robotics Board for BBC micro:bit.

Dimensions:

Length: 68mm.

Width: 46.5mm.

Height: 10.6mm.

PCB Thickness: 1.6mm

Kitronik's Simple Robotics Kit is an easy build, entry-level, introduction to the exciting world of robotics. Step-by-step build and coding instructions are included.

Enter the world of robotics with our Simple Robotics kit and build your own easy build microbit-controlled robot. It has been designed, from the ground up, to be simple to build by even the youngest of fingers. From its one-piece cardboard chassis to its clip lead connections, everything goes together in a way that is as free from frustration as possible.

This robot buggy is the same that is featured in our Lesson in a Box Simple Robotics kit, which is a complete set of electronics and teaching resources to enable successful cross-curricular lessons with minimal teacher effort. This single version allows you to make one at home with the children and enjoy the fun learning potential this kit offers. Designed and tested with direct Teacher assistance, and in the classroom, we know this kit lends itself perfectly to the young roboteer.

The kit of parts is accompanied by a detailed set of instructions that will not only walk you through the assembly but also covers the coding in detail. Even if you aren't confident or technical in nature, you will have no difficulties assembling and using this wonderful kit. Nearly everything you will need is supplied with the kit. All you need to have to hand is; a microbit, a screwdriver, and a pair of scissors. The scissors and the screwdriver are barely used, so if the children are quite young these parts can be done in a flash by an adult. The included cardboard body can be cut, decorated, and modified to suit your own projects, or you could even design your very own chassis, the possibilities are endless.

Coding: The supplied instructions have extremely detailed coding explanations, so much so that the beginner will have no difficulties following along. There are also some more involved examples that are similarly walked through. The examples are for the Microsoft MakeCode Editor, which is also designed for beginners.

Features:

An easy-build entry-level robot kit that requires no soldering.

It contains detailed instructions for both the assembly and the coding.

The included cardboard body can easily be customised and decorated.

A great activity to do with supervised children.

It can be coded with the easy-to-use Microsoft MakeCode Editor, which the included instructions cover in detail.

Contents:

1 x Klip Motor Driver for BBC microbit.

2 x Wheels and Tyres.

1 x Set of Clip Leads.

2 x Right Angle Geared Hobby Motor.

1 x Solderless TT Motor Board.

1 x Ping Pong Ball.

1 x Rubber Band.

1 x Cardboard chassis net.

Motor:bit is a motor driving board based on micro:bit. It has integrated a motor driving chip, which is used to drive two motors with maximun 1.2A DC single channel current. It has also integrated 12 GVS ports (for connecting OCTOPUS series of electric bricks) and 1 IIC communication port. These ports allow you to extend with various sensors and electric modules.

On the board, P3-P7, P9-P10 are IO ports for directly driving 3.3V devices; P13-P16, P19-P20(IIC port) support 3.3V/5V voltage switch. Sliding the voltage switch onboard, it is available to drive 3.3V or 5V devices. Besides, you can play music with the buzzer on motor:bit. Motor:bit is totally designed for DIYers. You can use it to create your own smart car or any funny projects.

FEATURES

Support 2 DC motors.

Max driving current of single channel is 1.2A.

Extend 14-channel IO ports and lead out it by GVS pins. Among it, 6 ports support 3V/5V voltage switch.

With 1 passive buzzer on board.

The ElecFreaks Cutebot is a rear-wheel drive smart car designed for the micro:bit, featuring two powerful motors for fast and responsive movement. Packed with built-in features, it includes an ultrasonic distance sensor, dual RGB headlights, underglow position lights, two line-following sensors, and a buzzer that functions as a horn.

Cutebot is fully compatible with graphical programming platforms, allowing learners to progress from simple coding tasks to more advanced robotics challenges. With its interactive features and user-friendly design, it’s the perfect tool to introduce children to coding, electronics, and hands-on problem-solving.

Note: micro:bit is not included
